Wifi Controlled Water Valve



The VC100 Ball Valve is an innovative motorized ball valve that incorporates advanced smart control capabilities. With the integration of a smart control function, this valve can be conveniently operated using a mobile application on compatible devices. By establishing a network connection to Wi-Fi, users can remotely control the valve's opening and closing states.



The smart control feature of the VC100 Ball Valve allows users to have real-time control over the valve's operation through a dedicated mobile app. By simply downloading the app and connecting the valve to their Wi-Fi network, users can adjust the valve's position and monitor its status from anywhere at any time.





• Smart Control : The valve can be controlled by mobile device, it means you can remote control by mobile device
• Open Percentage : The open percentage can be selected on the operation interface to finely control the flow rate of the medium;The valve can be adjusted 0~100% opening to control the flow rate
• Schedule Setting : It will automatically open or close as soon as the scheduled time is up after the time is set.
• IP Rating: IP65
• 18 month warranty
• Excellent after service
• Professional technical support
• OEM available





Valve Body Parameters

*Note: unit:mm; H/L/D refers to valve body materials and caliber specifications, with a tolerance of ±1mm



Material	Caliber	Interface Type	D	L	H
Stainless Steel	DN8	2-Way internal thread G1/4	1/4''	50	88
	DN10	2-Way internal threadG3/8	3/8''	50	88
	DN15	2-Way internal thread G1/2	1/2''	57	96
	DN20	2-Way internal thread G3/4	3/4''	60	96
	DN25	2-Way internal thread G1	1''	70	103
	DN32	2-Way internal thread G11/4	1-1/4''	80	111

Material	Caliber	Interface Type	D	L	H
Copper	DN8	2-Way internal thread G1/4	1/4''	50	88
	DN10	2-Way internal threadG3/8	3/8''	50	88
	DN15	2-Way internal thread G1/2	1/2''	57	96
	DN20	2-Way internal thread G3/4	3/4''	60	96
	DN25	2-Way internal threadG1	1''	70	103
	DN32	2-Way internal thread G11/4	1-1/4''	80	111

Material	Caliber	Interface Type	D	L	H
PVC	DN15	2-Way internal thread G1/2	1/2''	60	104
	DN20	2-Way internal thread G3/4	3/4''	72	108
	DN25	2-Way internal thread G1	1''	50	118



Technical Parameters

Valve Body Diameter: DN8~DN32	IP Rating: IP65	Connection Method: 2-Way internal thread G
	Output Torque: 2Nm
Applicable Medium: Water	Communication Method: WIFI MeterTube APP: Available	Valve Body Material: Brass, Stainless Steel, PVC
Power Supply Voltage: DC5V
Maximum Power: 3W	Controller Operation: Remote control via MeterTube mobile APP	Medium Temperature: Brass≤100°C, Stainless Steel≤100°C, PVC≤0°C







• Water Treatment Systems: Wi-Fi ball valves can be used for flow control and valve control in water treatment systems. By remotely controlling the on/off status of the ball valve, the flow of water can be regulated and controlled, improving the efficiency and convenience of water treatment systems.
• Industrial Process Control: Wi-Fi ball valves are widely used in industrial process control. For example, in chemical plants, Wi-Fi ball valves can be used to control the flow of liquids or gases in pipelines, achieving precise control over the process.
• Smart Home Systems: Wi-Fi ball valves can be integrated with smart home systems to enable remote control of water, gas, etc. Users can easily control the on/off status of the ball valve through devices such as smartphones or smart speakers, achieving intelligent management of the home environment.
• Agricultural irrigation system: Wi-Fi ball valves can be integrated with agricultural irrigation systems to achieve remote control of irrigation equipment. Farmers can use a mobile application to schedule or manually control the status of the ball valves, adjusting the irrigation amount and frequency in the fields to improve irrigation efficiency.





Gentos collaborates with clients to optimize fluid resource utilization, offering comprehensive solutions for energy preservation, emissions control, and precise measurement. Their ultrasonic flow meters, powered by transit-time patent technology, are widely used in various industries and research institutions. Gentos values employee growth and development through training programs and transparent promotion procedures. They prioritize the progression of experienced professionals while introducing managerial expertise at various levels for continuous growth. Gentos is committed to providing innovative and eco-friendly solutions that meet customer needs and contribute to a sustainable future.



Company environment display：



Certificate display：



Deliver, Shipping, and Serving





Endeavoring to exceed customer expectations, Gentos has implemented an accelerated delivery system, ensuring the timely arrival of products. Steadfastly, Gentos expedites order processing and swift product dispatch within an efficient 2 to 3-day duration. Empowered by a wide assortment of transportation and express delivery options, Gentos prioritizes customer satisfaction.





Q: What is a smart water shut-off valve?

A: A smart water valve is a device that allows for remote control and monitoring of water flow in a plumbing system. It is designed to provide convenience, efficiency, and water damage prevention by allowing users to shut off or control the water supply to their homes or specific areas remotely using a smart phone or other smart devices.



Q: What are the disadvantages of shut-off valve?

A: As for water valves that work with Ring, Ring is primarily known for its video doorbells and security cameras. While Ring does not manufacture water valves directly, they have integrated their devices with some smart home platforms like Z-Wave or Zigbee. By using a compatible smart home hub or controller, you may be able to connect certain smart water valves to your Ring system for enhanced control and monitoring.



Q: What is a water stop valve?

A:A water stop valve, also known as a shut-off valve or isolation valve, is a device used to control the flow of water in a plumbing system. It is typically installed at various points in the water supply network, such as under sinks, behind toilets, or near appliances, to allow for easy shut-off of water in case of emergencies, repairs, or maintenance. Water stop valves are essential for quickly stopping the flow of water to prevent flooding and water damage.



Q: Which valve turns off water?

A: The valve that is commonly used to turn off the water supply is called a shut-off valve. Shut-off valves are designed to stop or control the flow of water in a plumbing system. They can be found at various points in the water supply line, such as near fixtures, appliances, or at the main water supply entry point to a building. Shut-off valves can be manually operated or equipped with automation features for remote control.



Q: How does a smart water valve work?

A: A smart water valve, such as a Wi-Fi ball valve, works by integrating with a network and being controlled remotely through a mobile device or a smart home system.
