Your Professional Portable Ultrasonic Flow Meter Supplier
Gentos Measurement & Control Co., Ltd is a leading manufacturer of ultrasonic flowmeters with over three decades of experience in fluid measurement.
Our pFlow brand has gained a strong reputation and is highly regarded in Asia, Europe, and America. Gentos Product line includes Clamp on flowmeters, BTU meters, IoT Ball Valves, providing versatile solutions for various applications.
Why Choose us
Customized Service
We offer tailored flow measurement solutions designed to meet the specific requirements of diverse industries.
Comprehensive Product Qualifications
Our company has successfully obtained certifications under the GB/T 19001-2016/ISO 9001:2015 international quality management system and the GB/T 24001-2016/ISO 14001:2015 environmental management system standards.
Extensive Experience
With more than 30 years of accumulated expertise in fluid measurement, we deliver reliable and high-performance solutions across a wide range of applications.
Parameter
|
Performance Index |
|
|
Flow velocity |
±0.03 ~ ±40 ft/s (±0.01~ ±12 m/s) |
|
Accuracy |
±0.5% of measured value |
|
Repeatability |
0.15%. |
|
Linearity |
±0.5%. |
|
Pipe Size |
Clamp-on:1″~ 48″ (25mm~1200mm) |
|
Functional Index |
|
|
Outputs |
Analog output: 4~20mA, Max 750 Ω., Modbus RS 485, OCT Pulse, Relay |
|
SD card |
Storage: 8GB; Max: 512 files; Interval: 1 ~ 60 seconds. |
|
Power supply |
Rechargeable Lithium Battery Power . (continuous operation of mainbattery 10 hours). |
|
Keypad |
Tactile Keys. |
|
Display screen |
3.5 inch TFT screen( 320 × 240 ), backlit LCD. |
|
Humidity |
Relative humidity 0~99%, No condensation |
|
Temperature |
Transmitter(Ambient): 14℉~122℉(-10℃~50℃) Transducer-P010(Fluid): - 40℉~176℉(-40℃~80℃) Transducer-PH020(Fluid): -40℉~302℉(-40℃~150℃) |
|
Physical Characteristics |
|
|
Transmitter |
NEMA13 ( IP54 ). |
|
Transducer |
Encapsulated design, IP68; Standard cable length: 5m. |
|
Network Cable |
Transmitter: Approximately1.0kg. |
Benefits of Portable Ultrasonic Flow Meter
Clamp-On Models: These attach externally to the pipe, eliminating the need for process shutdowns or pipe modifications.
Benefit: Cost savings in installation and reduced downtime.
Transit-Time Technology: Provides precise readings for clean liquids.
Doppler Technology: Ensures accuracy in fluids with bubbles or particulates.
Benefit: Reliable measurements even in dynamic conditions.
Works with various pipe materials, including metal, plastic, and concrete.
Suitable for measuring different fluids, from clean water to viscous slurries.
No moving parts mean minimal wear and tear.
Maintenance costs are lower compared to traditional flow meters like turbine or mechanical meters.
Can be used for portable or fixed installations.
Works for fluids at extreme temperatures or pressures, depending on the model.
Non-contact operation reduces the risk of leaks or contamination.
Ideal for sensitive applications, such as in food and beverage or pharmaceuticals.
Compatible with SCADA, IoT platforms, and advanced monitoring systems.
Outputs include analog signals, digital interfaces, and wireless communication.
Water and Wastewater: Measure flow in treatment plants or pipelines.
HVAC Systems: Optimize chilled water and heating loops.
Oil and Gas: Non-intrusive measurement for crude oil and refined products.
Food and Beverage: Safe, hygienic measurement for clean fluids.
Chemical Processing: Monitor corrosive or high-viscosity fluids without exposure.
We will help you to choose the best shipping way according to your detail requirements. By sea, by air, or by express, etc.
1. The time frame of an order delivery is divided into two parts:
Processing time: 7-14 Days
Shipping time: 20~30 Days
2. Shipping methods: DDP, DAP, EXW, etc.
3. Shipping fee: The shipping fee will be changed according to every pacel's weight.
Certificate
FAQ
As one of the most professional portable ultrasonic flow meter manufacturers and suppliers in China, we're featured by quality products and good service. If you're going to wholesale customized portable ultrasonic flow meter, welcome to get pricelist and quotation from our factory.
Waste Water Meter, HVAC BTU Meter, Chilled Water BTU Meter
