Brief Introduction
|
Accuracy: |
±2%,(1.0~16f/s) |
Pipe size : |
DN20~DN80 |
|
Repeatability |
0.2% |
Flow Velocity |
0.1~16ft/s(0.03~5.0m/s) |
|
Temperature: |
Transmitter: 14 °F to 122 °F(-10℃~50℃) |
||
Product Introduction
The F3P Embedded Ultrasonic Flowmeter is an advanced POE Flow Meter specifically designed for applications like Laundry Water Usage monitoring. It utilizes ultrasonic transit time technology to measure water flow accurately, ensuring precise tracking of water consumption in laundry facilities.
With its easy installation and clamp-on design, the F3P can be quickly set up without disrupting existing pipelines, making it ideal for retrofitting in laundries.
The POE power supply and Ethernet communication enable seamless cloud data storage, allowing managers to monitor and analyze Laundry Water Usage in real-time via the MeterTube App. This feature is crucial for optimizing water efficiency, identifying leaks, and reducing operational costs in laundry operations.
The F3P's high accuracy and reliability make it a valuable tool for sustainable water management in the laundry industry.
Product Applications
●Laundry Water Usage
●Fish Production System and Fish Hatchery
●Food and Beverage Processing (Milk, Drink, Juice, Beer, Wine)
●HVAC (Heating, Ventilation, and Air Conditioning)
●Water and Wastewater Management
●Pharmaceuticals and Biotechnology
●Pulp and Paper Manufacturing
●Agriculture and Aquaculture
●Environmental Monitoring
●Chemical Processing
●Marine Applications
●Power Generation
Product Parameter
1)Technical Parameters
|
Performance Index |
|
|
Flow Velocity |
0.1~16ft/s(0.03~5.0m/s) |
|
Accuracy |
±2%,(1.0~16f/s) |
|
Repeatability |
0.2% |
|
Pipe Size |
DN20~DN80 |
|
Medium |
Water |
|
Pipe Material |
Carbon Steel, Stainless Steel, Copper, PVC |
|
Functional Index |
|
|
Communication Protocol |
Support HTTP Protocol and MOTT Prtocol |
|
Power supply |
POE network cable power supply |
|
Key |
4 keys |
|
Display Screen |
1.44 " LCD colorful screen, resolution 128 *128 |
|
Temperature |
Transmitter: 14 °F to 122 °F(-10℃~50℃) |
|
Humidity |
Relative humidity 0~99%,No condensation |
|
Physical Characteristics |
|
|
Transmitter |
Plate mounted type |
|
Transducer |
Clamp on Standard cable length: 9m |
|
Network Cable |
POE network cable, standard length:2m |
2)Body Parameters
Transmitter Dimension
Component Parts Dimension
Meter Wiring
Back view
3)Appearance
Compatible Pipe Materials
Detectable Fluids
1.Installation of the main parts
2.Installation of upper tube clamp and rail assembly
3.Istallation of transducers
After locking the pipe clamp, if it still appears loose, you can paste the black rubber
pad (2mm thick)included in the accessory bag on both sides of the inmer wall of the
pipe clamp.
Product Qualification:
For more than three decades, Gentos has been at the forefront of manufacturing top-notch, competitively priced ultrasonic flow meters, earning a reputation for excellence. We are industry leaders in innovation and eco-friendly products, striving to elevate industry standards while keeping costs reasonable.
As our product line continues to evolve, we remain committed to enhancing functionality and pushing the boundaries of quality and performance. Throughout the process of designing new products, we actively seek input from our valued customers, recognizing their invaluable contributions in shaping our success. It is through this collaborative approach that we have carved out a distinctive position in an industry that demands a seamless fusion of safety and performance.
Company environment display:
Certificate display：
Deliver, Shipping, and Serving
Direct support：
Qucik response：
Fast delivery：
Shipping
Nurturing seamless customer experiences, Gentos has implemented an expedited delivery system, ensuring prompt product acquisition. Effortlessly, Gentos expedites order processing and swift product dispatch within an efficient 1 to 3 days window. Featuring an extensive selection of transportation and express delivery options, Gentos caters to the unique preferences of each customer.
FAQ
Q: Are you a trading company or a factory?
A: We have been focusing on ultrasonic flowmeters for 32 years and we are a well-known manufacturer integrating R&D and factory.
Q: What are the advantages of ultrasonic flow meters?
A: They offer non-invasive measurement, high accuracy, resistance to fluid property variations, suitability for various fluids, and low maintenance requirements.
Q: How do you install a flow meter?
A: Follow the manufacturer's installation instructions or view our youtube installation video.
Q: How to choose the right flow meter model for you?
A: Contact our technical sales with your pipe material and diameter, and we will recommend the most suitable model.
Q: Can this water meter track water usage?
A: Yes, it's designed to monitor and track water usage, detecting leaks in real time and helping manage water budgets effectively.
