Brief Introduction
Carry the P117 wherever you need to assess flow rates-no permanent installation required.
Product Introduction
Body Parameters
Appearance
Technical Parameters
|
Performance Index |
|
|
Flow Rage |
±0.03ft/s ~ ±40 ft/s ( ±0.01m/s ~ ±12 m/s ) |
|
Accuracy |
±0.5% of measured value . ±1.5 ft/s ~ ±40 ft/s (±0.5 m/s ~ ±12 m/s) |
|
Repeatability |
0.1% |
|
Medium |
Water |
|
Pipe Size |
1″ ~ 200″ ( 25 mm ~ 5000 mm ) |
|
Functional Index |
|
|
Communication Interface |
RS485 |
|
Output |
Analog output: 0/4 ~ 20 mA, ( max load 750 Ω ); Pulse output: 0 ~ 9999 Hz, OCT ( min. and max. frequency is adjustable ); Relay output: max. frequency 1Hz ( 1A@125VAC or 2A@30VDC ) |
|
Standard SD card |
Maximum storage period: 512 days, storage interval: 1-3600 seconds |
|
Power supply |
90 ~ 245 VAC (48 ~ 63 Hz) Or 10 ~ 36 VDC. |
|
Keypad |
22 light tactile keys |
|
Display |
20 × 2 lattice alphanumeric, backlit LCD. |
|
Humidity |
Up to 0 ~ 99% RH, non - condensing |
|
Temperature |
Transmitter: 14°F ~ 122 °F (- 10℃ ~ 50℃ ). Transducer: -40 °F ~ 176 °F ( - 40 ℃ ~ 80 ℃, standard ). |
|
Physical Characteristics |
|
|
Transmitter |
Die-cast aluminum, IP65. |
|
Transducer |
Encapsulated design. IP68. Standard / Maximum cable length: 30 ft / 1000 ft ( 9m / 305 m ). |
|
Weight |
Transmitter: approximately 4.7 lb ( 2.15 kg ). Transducer: approximately 2.0 lb ( 0.9 kg ). ( standard ) |
Product Applications
Product Qualification
For more than three decades, Gentos has been at the forefront of manufacturing top-notch, competitively priced ultrasonic flow meters, earning a reputation for excellence. We are industry leaders in innovation and eco-friendly products, striving to elevate industry standards while keeping costs reasonable.
As our product line continues to evolve, we remain committed to enhancing functionality and pushing the boundaries of quality and performance. Throughout the process of designing new products, we actively seek input from our valued customers, recognizing their invaluable contributions in shaping our success. It is through this collaborative approach that we have carved out a distinctive position in an industry that demands a seamless fusion of safety and performance.
Company environment display：
Certificate display：
Deliver, Shipping, and Serving
Shipping
Nurturing seamless customer experiences, Gentos has implemented an expedited delivery system, ensuring prompt product acquisition. Effortlessly, Gentos expedites order processing and swift product dispatch within an efficient 2 to 3-day window. Featuring an extensive selection of transportation and express delivery options, Gentos caters to the unique preferences of each customer.
FAQ
1. Q: Why is flow measurement important in water saving?
A: Clamp-on ultrasonic flow meters are used to measure accurate waste water flow rates. Flow meters are also crucial to the clarification, filtration, and treatment stages. The flow must be carefully observed to adjust the number of coagulants and polymers needed for proper filtration.
2. Q: Why flow meters are important in water saving?
A: Because it can accurately measure and control flow in real time, through precise flow control and monitoring, it can effectively reduce the waste and loss of water resources and achieve sustainable use of water resources.
3. Q:What is the purpose of this flow meter?
A: Smart water meters have many broad applications in real life, such as residential water measurement, ultra-pure water measurement, monitoring of aquaculture systems, HVAC chilled water measurement and agricultural irrigation.
4. Q: How do you install an air conditioner flowmeter?
A: Follow the manufacturer's installation instructions.
5. Q: How to choose the right flowmeter model for you?
A: Please contact our technical sales with the product you are interested in, after confirming your pipe material and pipe diameter, we will recommend the most suitable flow meter model for you.
